Secondary Packaging Line Machine

Key Features of The Baling Packing Machine Production Line

This bag-in-bag automatic packing machine solution is a customized integrated production line. The solution includes the primary bag packaging machine, the transitional conveyor line, and the baling system. The primary bag packing machine generally connects with the raw material silo with a material level sensor to realize a continuous production process. To ensure the best product quality, the automatic check weigher and metal detector with a rejecting system are always equipped to reject unqualified products. Meanwhile, this production line is mostly used to pack standard weights of 500g or 1000g for uniform materials.

The full system adopts a high-standard configuration to ensure the best running performance. The primary and baling systems use Siemens PLC and HMI with customized programs. The other pneumatic and electrical parts all adopt internationally famous brands like SMC, Schneider, Mettler Toledo, Sick, or Equal brand. All the materials used to contact the parts are made of food-level stainless steel. The other parts are polished stainless steel or coated carbon steel with a better appearance.

This bag-in-bag baling packing machine production line is only suitable for LLDPE single-layer film packaging. To better ensure the sealing performance, the heat-sealing system for both the primary packaging machine and the baling packaging machine all adopts Germany Ropex sealing control system. The LLDPE single-layer film has the key feature of being soft and extending, it could better protect the primary bags during the free-dropping process. The traditional laminated packaging material shall form sharp angels and it will be easy to overturn in the dropping action.

This line includes:

• Horizontal belt conveyor for primary packaging machines (2kg bag packaging machine).
• Slope arrangement belt conveyor.
• Acceleration belt conveyor.
• Counting and arranging machine
• AFS1100 bagging machine
• Take off the conveyor belt one set.

Work Process:

• Slope arrangement conveyor will make the pouches flat before counting.
• Acceleration belt conveyor will make the adjacent pouches leave enough distance for counting.
• Counting and arranging machine will arrange the small pouches as required.
• The small pouches will be loaded into the AFS1100 bagging machine.
• WT bagging machine will seal and cut the big bag.
• Belt conveyor will take the big bag under the WT machine.

Features:

• Automatic packing machine has functions of automatic lm pulling, bag making, filling, and sealing.
• Operation through touch screen. Convenient, safe, and reliable.
• Can meet requirements of different pouch arranging forms.
