BAGGING MACHINE FEATURE FOR MULTILANE STICKPACK
- CE Marked European Automation equipped with PLC & Touch-Screen HMI
- Servo Motor driven film-pulling system for precise length control
- Pneumatic cylinder-driven sealing system for effective sealing pressure
- Motion Type horizontal jaw for faster output
- Sturdy, versatile & compact construction of machine
- Linkage system for easy operation of the machine
- Film roll transport mechanism for better monitoring of the film travel
- Motorized film reel unwinding control
- Built-in safety door guards with machine–off interlock
- Build-in Jumbo Roll Trolley suitable for 300 mm dia./40 kg film roll
- Electricals housed in separate panels with IP 54 series enclosures
- End-of-film roll with machine-packing mode interlock
- Integration to upstream and downstream machines/systems
- Easy replacement of forming and auger size part
- Full body made of Stainless Steel
- Machine Dimension: L2300*W2200*H3550mm
- Machine Weight: 1500 Kg
